260 Beam Light Japanese Phoenix Bulb
260 Beam Light Japanese Phoenix Bulb
Feature: adopt photoelectric reset for horizontal and vertical, when error occurs
Automatic retrieval and reset after operation; three-phase stepping motor makes operation
Faster and smoother operationBuilt-in overheating protection and intelligent cooling system
System, remote control bulb switch and power
Automatic retrieval and reset after operation; three-phase stepping motor makes operation
Faster and smoother operationBuilt-in overheating protection and intelligent cooling system
System, remote control bulb switch and power
Technical parameter
260 Beam Light Japanese Phoenix Bulb
YF-6260M
Voltage: AC100-240V 50/60Hz
Work rate: 450W
Light source: MSD YF-280W
Ballast: electronic ballast
Channel: 17 channel mode
Color: one color wheel, 13 color chips + white light
Pattern: a fixed pattern plate, 10 patterns + 3 glass patterns + white light
Prism: two rotatable prisms, one 16 prism and a 32 prism
Atomization: Gradual atomization, dyeing angle 5-30 degrees
Stroboscopic: 0.5-14 times/second, multiple stroboscopic effects
Optics: high-precision glass optical lens, linear zoom 0-20 degrees
Movement angle: horizontal 540 degrees, 8/16Bit resolution, Vertical 270 degrees, 8/16Bit resolution
Protection level: Ip20
Net weight: 18Kg
Packing size: 380*260*600mm
