311W Beam Light
311W Beam Light
Features: horizontal and vertical use photoelectric reset, when an error occurs
Automatic retrieval and reset after operation; stepper motor makes operation
Faster and smoother operationBuilt-in overheating protection and intelligent cooling system
System, remote control bulb switch and power
Automatic retrieval and reset after operation; stepper motor makes operation
Faster and smoother operationBuilt-in overheating protection and intelligent cooling system
System, remote control bulb switch and power
Technical parameter
311W Beam Light
YF-311BEAM
Voltage: AC100-240V 50/60Hz
Power: 380W
Light source: original OSRAM 311W
Ballast: electronic ballast
Channel: 16 channel mode
Color: one color wheel, 13 color pieces + white light
Pattern: a fixed pattern plate, 10 patterns + 3 glass patterns + white light
Prisms: two rotatable prisms, one 16 prism and one 8+8+8 prism
Atomization: Gradual atomization, dyeing angle 5-30 degrees
Colorful: gradient colorful
Stroboscopic: 0.5-14 times/second, multiple stroboscopic effects
Optics: high-precision glass optical lens, linear zoom 0-20 degrees
Movement angle: horizontal 540 degrees, 8/16Bit resolution, vertical 270 degrees, 8/16Bit resolution
Protection level: Ip20
Net weight: 18Kg
Packing size: 380*260*600mm
