380W Beam Light
YF-8380B
Voltage: AC100-240V, 50/60Hz;
Light source: Osram SIRIUS HRI 371W (optional Philips 380W)
Average life: 2000H
Total power: 600W (with PFC switching power supply)
Color temperature: 7800K
Display: 2.8-inch widescreen LCD touch screen, Chinese and English display interface, can be reversed 180 ° display.
Channel mode: 16/24CH;
Color wheel: 14 colors + white (color rainbow can be achieved)
Fixed patterns: 17 patterns + white.
Rotating patterns: 9 patterns + white (Gobos can be quickly disassembled, variable-speed jitter, interchangeable rotating gobos can realize autobiography, running water, and jitter effects, and the patterns can be positioned at any angle.
Prism: 8 prism + 16 prism, (16+24 prism can be combined at will)
Effect pattern: 1 dynamic effect wheel with two-way flow.
Focusing: linear electric focusing, the light beam can be large or small linearly magnified, the rotating pattern is 6.5 to 50°, the fixed pattern is 3.5 to 32°
Atomization: Imported high temperature resistant atomization film, 0%-100% atomization, atomization soft light dyeing effect, dyeing angle 6-50 degrees, can be used as fixed-point chasing surface light.
Dimming: 0%-100% mechanical dimming is smooth and flicker-free, two-chip strobes can be adjusted for 0.5-14 times per second, the power of the strobe lamps is turned off, energy saving and environmental protection, support strobe macro functions (pulsation, synchronization, asynchronous ,random)
Motor: XY axis three-phase motor drive (silent, fast without running)
Rotation angle: X-axis 540 degrees, Y-axis 270 degrees can automatically correct positioning. The horizontal and vertical quick locks are convenient for product transportation and maintenance.
Other functions: DMX can remotely control the light bulb switch function, the console can turn on and off the bubble, and at the same time can set the power-on light bulb function on the display board. The display screen can display the lamp and bulb use time, and the fan can automatically adjust the speed.
Lamp appearance: high temperature resistant plastic + molded alloy material (using high-strength PA66 material with high temperature resistance, flame retardant, anti-aging, wear-resistant, lightweight and anti-fall characteristics) Operating temperature: -45°C to 70°C, bulb with overheat protection .
Anti-radiation coating optical glass lens group, the lens is coated with 6 layers of full film inside and outside, and the light transmission is better. The special optical system of Mingfeng makes the beam feel stronger, the beam is more solid, there are no virtual edges, and the beam is clean and full.
Protection level: IP20 protection level, optional rain cover protection level will reach Ip44
